Leica Rugby 640G — Article No. 6011487
Green Beam Rotary Laser Package with Rod Eye 120G Receiver, RC400 Multipurpose Remote, A-600 Li-Ion Battery Pack & Charger
The Leica Rugby 640G (Article No. 6011487) is the complete professional package for contractors who demand visibility, range, and control on every job. This green beam rotary laser delivers four times the visibility of a red beam — making it the go-to choice for interior finish work, exterior grading, and everything in between.
Unlike the standard alkaline package, the 6011487 includes the RC400 Multipurpose Remote Control for hands-free operation up to 200 m (650 ft), the A-600 Rechargeable Lithium-Ion Battery Pack with charger for up to 40 hours of runtime, and the Rod Eye 120G Green Receiver with digital readout for outdoor detection up to 400 m (1,300 ft).
▪ Package 6011487 Includes
- Leica Rugby 640G Green Beam Rotary Laser
- Rod Eye 120G Green Laser Receiver with Bracket (849525) — 400 m / 1,300 ft range
- RC400 Multipurpose Remote Control — operates laser up to 200 m / 650 ft
- A-600 Rechargeable Li-Ion Battery Pack — up to 40 hours runtime
- Battery Charger
- Leica Hard Carrying Case
Why Choose the Rugby 640G?
|
🌿 4x Brighter Green Beam
Visible up to 30 m (100 ft) without a receiver. The 520 nm green diode technology is four times more visible to the human eye than red beam lasers — ideal for brightly lit interiors and outdoor use.
|
📶 RC400 Remote Control
Control the laser from up to 200 m (650 ft) away. Change rotation speed, activate scanning, switch planes, and set Scan90 — all without touching the instrument.
|
|
🔋 A-600 Li-Ion Battery — 40 Hours
The rechargeable A-600 pack delivers up to 40 hours per charge. No hunting for AA batteries mid-job. Charger included in the kit.
|
🎯 Rod Eye 120G — 1,300 ft Range
The RE120G green receiver with digital readout detects the Rugby 640G out to 400 m (1,300 ft) outdoors, with convenient offset readings for grading and layout applications.
|
|
☁️ IP67 Dust & Waterproof
Fully sealed against dust ingress and submersion. Works in rain, concrete dust, drywall environments — wherever the job takes you.
|
◢️ Scan90 & Dual-Axis Manual Slope
Scan90 sweeps the beam 90° left or right for fast squaring and layout. Dual-axis manual slope lets you set independent grades in X and Y simultaneously.
|
Ideal Applications
- Suspended ceilings, raised floors, and drywall installation
- Site grading, drainage, and excavation layout
- Interior leveling, squaring, and alignment
- Plumbing and HVAC rough-in work
- Foundations, formwork, and concrete flatwork
- Any outdoor or indoor application requiring extended range and hands-free control
Technical Specifications
| Specification |
Value |
| Article No. | 6011487 |
| Laser Class | Class 2 |
| Laser Wavelength | 520 nm (Green) |
| Accuracy | ±2.2 mm at 30 m (±3/32” at 100 ft) |
| Self-Leveling Range | ±5 degrees |
| Functionality | Self-leveling; Horizontal & Vertical; 90°; Dual-axis manual slope |
| Rotation Speeds | 0, 2, 5, 10 rps (0, 120, 300, 600 rpm) |
| Scanning Modes | 10°, 45°, 90° (Scan90) |
| Plumb Up / Plumb Down | Yes / Yes |
| Visible Range (no receiver) | Up to 30 m (100 ft) indoors |
| Max Range with Rod Eye 120G | 400 m (1,300 ft) |
| RC400 Remote Range | 200 m (650 ft) |
| Battery Type (this package) | A-600 Rechargeable Li-Ion |
| Runtime — Li-Ion | Up to 40 hours |
| Runtime — Alkaline (optional) | Up to 60 hours |
| Working Temperature | -20°C to +55°C (-4°F to +122°F) |
| Protection Rating | IP67 (dust-tight & waterproof) |
| Tripod Thread | 5/8”-11 |
| Elevation Alert | Yes |
| Sleep Mode | Yes |
| Warranty | 3-Year Limited Lifetime |
Leica Rod Eye 120G Receiver — Included in This Package
|
Built for the Rugby 640G Green Beam
The Leica Rod Eye 120G receiver is designed specifically to capture the green laser beam of the Rugby 640G rotating laser. Its tuned photodetector locks onto the 520 nm wavelength for maximum accuracy and outdoor range. The digital readout makes height readings and work with offsets convenient and fast, while the 7 cm detection window allows beam detection up to 200 metres radius (400 m diameter).
Detection Range: 400 m / 1,300 ft
|
Rod Eye 120G Key Features:
|
✓ LCD indication — two large graphic displays on the front and back of the receiver for easy reading from any angle
|
✓ Digital readout — measures offset from Rugby 640G beam position, adding convenience and saving time on layout and grade work
|
|
✓ Audio indication — three volume levels: loud, soft, off — hear the beam even in noisy environments
|
✓ Accuracy (bandwidth) indication — three accuracy levels: fine, medium, coarse for fast rough-in or precise finish work
|
|
✓ Built-in 7 cm detection window — allows easy detection of the beam over the entire working distance, even in bright outdoor conditions
|
RC400 Multipurpose Remote Control — Included
The RC400 Remote gives you full command of the Rugby 640G from anywhere on the jobsite — up to 200 m (650 ft) away. Functions controllable via RC400:
- Power on / off
- Rotation speed adjustment (0, 2, 5, 10 rps)
- Scan mode activation (10°, 45°, Scan90)
- Vertical plane switching
- Sleep mode toggle
6011487 vs. 6011486 — What’s the Difference?
The 6011487 (this package) adds the RC400 Remote Control and upgrades the battery to the A-600 Rechargeable Li-Ion Pack with Charger. The 6011486 ships with an alkaline battery tray and no remote. If you work solo or need hands-free operation at range, the 6011487 is the right choice.
Leica Geosystems is the global standard in precision measurement instrumentation. The Rugby series has been the preferred rotary laser for professional contractors for over two decades — trusted for accuracy, ruggedness, and unmatched after-sales support. Contractors-Tools.com is an authorized Leica Geosystems dealer. All products carry the full manufacturer warranty.
Questions? Call us at 877-866-5721 — our team knows this product inside and out.
