Set grade on both axes, -10% to +10% on X and -0.5% to +25% on Y, from the RC703 radio remote up to 750 ft away, and the GL722 self-levels to it. Read it on the CR600, on the grade rod or on the machine. Levels to 3/64″ at 100 ft across a 3,000 ft working diameter.
Questions? Talk to someone who uses these: 1-877-866-5721
Spectra Precision GL722-10 Dual Grade Laser with Radio Remote and CR600 Receiver
The GL722 Series gives you the right laser for the right job… this dual grade laser transmitter with an advanced, long range radio remote control. Further, the GL722 offers Long Range Remote Control, Grade Matching and Automatic Axis Alignment (with the 1446-8801S connector cable, sold separately for this kit) – to let you get to grade faster and with more accuracy. On site, you’ll find that the advanced features quickly translate into productivity and accuracy.
The GL722 features +/- 10% in the X axis grade range and -0.5 to +25% Y-axis grade range with high accuracy up to 3,000 foot diameter. The GL722 is ideal for general construction and machine control grade applications
With the GL722’s powerful, long-range remote control, it only takes one person to accurately set up and operate the grade laser. Even grade reverse is done in an instant. And for the first time, you can automatically control all the transmitter functions from inside the machine cab. The GL722 comes with a laser receiver standard, a rechargeable NiMH battery pack and charger, and the best service and support in the industry. With Spectra Precision’s GL722 Grade Laser you can count on quicker setups and more productivity … for more profitability.
Spectra Precision GL722-10 Laser FEATURES and BENEFITS
Precision High Accuracy, Extra Long Range Grade Laser
The GL722 Dual Grade Laser is one of Spectra Precision’s highest accuracy, longest range grade lasers.
The fully sealed, rugged aluminum housing, advanced leveling technologies, and temperature compensation make the GL722 laser the best choice for long distance applications and machine laser display.
Automatic Axis Alignment and Grade Match capability (with the 1446-8801S connector cable, sold separately for this kit). Ideal for general construction, site preparation and road construction
Temperature compensation
Temperature compensation provides accurate stable results regardless of temperature changes
All-day power
Long battery life and flexible power options keep the unit working throughout the day
Large displays
Large displays make the numbers easy to read, even from a short distance
Servo accuracy
Better than 5 arc second servo deadband accuracy for demanding high accuracy requirements
The GL722 features -10% to +10% in the X axis grade range and -0.5 to +25% Y-axis grade range with high accuracy up to 900 meters (3,000 feet) diameter. The GL722 is ideal for general construction and machine control grade applications
Looking at every dual grade laser we carry? The GL722 is the long range one with a radio remote.
What’s in the Box
What You Receive.
Spectra Precision GL722-10 Dual Grade Laser Package INCLUDES
GL722 Dual Grade Laser
X axis -10% to +10%, Y axis -0.5% to +25%, 3/64 in at 100 ft, built-in radio for the RC703, 3,000 ft diameter.
The current 2025 GL700 user guide is also downloadable below, in English and Spanish.
2-Year Warranty
Spectra warranty on the GL722 laser and the RC703 remote, materials and workmanship. Calibration is the owner’s job. The CR600 receiver carries 2 years.
GL722-10
⚠ No connector cable in this kit
This kit has no 1446-8801S connector cable. Without it, Automatic Axis Alignment and Grade Match do not work. The RC703 remote still changes and bumps grade from up to 750 ft. Add the 1446-8801S cable (sold separately) to use them.
1446-8801S Cable, CR600 Receiver to RC703 Remote Sold separately: $123.00
Source: Contractors-Tools.com field experience; Spectra GL700 user guide p.14 (the cable carries grade-display signals between the CR600 and the RC703) and chapter 5 (Automatic Axis Alignment and Grade Match use the RC703 and the receiver together on the grade rod).
The GL722-10 is the GL722 laser, RC703 remote, CR600 receiver, C50 clamp, C51 magnet, NiMH set, charger and case. Not included: 1446-8801S connector cable, 1446-8710 remote holster, 12 V external power cable.We customize kits so you get what you need to complete the job.
Need an infrared beam? The GL722IR is the same laser, RC703 remote and CR600 receiver with a 785 nm, Class 1 infrared beam, for work where a visible beam is a hazard, distracting or not permitted: $7,031.25. See the GL722IR · See every GL722 kit ↓
Kit builder
Add a tripod and grade rod. Build this kit.
Our GL722 kit builder opens with the CR600 already picked. Choose an aluminum, fiberglass or elevator tripod and a grade rod in inches or tenths, and see the whole kit at one price.
Change and read grade from the RC703 remote up to 750 ft away, even from inside the machine cab.
Aim the axis with one button
Automatic Axis Alignment, with the 1446-8801S cable (sold separately): rough the laser in within 40 degrees, then one button on the remote lines the axis up.
It knows when it has been bumped
The automatic off-grade sensor (HI alert) stops the laser if the tripod moves, so nobody grades to a bad number.
The pairing
The laser sets the grade. The RC703 changes it from anywhere.
GL722
It puts the grade up, on two axes.
Dual grade. X axis -10% to +10% and Y axis -0.5% to +25%; it self-levels to both.
3/64″ at 100 ft leveling accuracy (8 arc seconds), 0.001% grade resolution.
300 / 600 / 900 rpm. Use 600 for hand-held receivers and most machine control.
Built-in radio talks to the RC703: grade change, grade bump and Grade Reverse from the remote. Automatic Axis Alignment and Grade Match need the 1446-8801S cable (sold separately).
HI alert: bump the tripod and it stops instead of letting you work off a bad setup.
Fully sealed, waterproof aluminum housing with a protective lens hood.
CR600
On the rod or on the machine.
Mounts on a grade rod with the C50 clamp, or on a machine with the C51 magnetic mount.
A 4.5″ detection height, linear LCD and super-bright LED grade indicators, 270° reception.
Die-cast magnesium housing, rated for a 10 ft drop onto concrete.
Over 100 hours on three AA batteries. 2-year Spectra warranty.
What the three of them do together
The GL722 holds grade on two axes across a 3,000 ft circle. The RC703 changes and reads that grade from up to 750 ft, so one person sets up, changes and checks grade without walking back to the laser. Add the 1446-8801S connector cable (sold separately, not in this kit) to link the CR600 and the RC703 on the grade rod, and the laser can aim its own axis at your point (Automatic Axis Alignment) or measure a slope that is already there (Grade Match).
What you get
Laser, remote, receiver and power
Laser
The GL722 dual grade laser with its 1445-2900 NiMH battery set and the 1445-2093 worldwide charger.
Remote
The RC703 two-way radio remote.
Receiver
The CR600 receiver with the C50 rod clamp and C51 magnetic mount, plus the rugged carrying case.
Everything you need to set grade on day one.
The technical edge
Grade you never have to walk back for
Dual grade
Type the grade into the X and Y axes, at the laser or from the remote; the laser self-levels to both.
Automatic Axis Alignment
Rough it in within 40 degrees, press one button on the remote and the axis lines up on your point. Needs the 1446-8801S cable (sold separately).
Grade Match
The laser finds and shows the slope between itself and your point. Needs the 1446-8801S cable (sold separately).
Less math at the stake, fewer trips to the tripod.
What sets it apart
Range and control for big sites
750 ft radio remote
2.4 GHz digital radio, encrypted to its own laser: grade change, Grade Reverse and rotation speed from anywhere on the site.
HI alert
Knock the tripod and the laser and rotor shut down, so nobody digs to a bad number.
Set it up once and run it all day.
Free Same-Day Shipping · Order by noon central and it ships today. Call 1-877-866-5721 for express and next-day options. · Two-year Spectra laser warranty
On the job. A Spectra GL722 dual grade laser with its radio antenna on a tripod over a graded site, dozers working to the beam.
Key Features
Built for the Jobsite.
Spectra Precision GL722 - BUILT FOR THE JOBSITE
Active Temperature Compensation
Accurate, stable results regardless of temperature changes
Long-Range Wireless Link
Unaffected by direction or sunlight
Protective Lens Hood
Ensures laser performance in inclement weather
Manual Alignment Sights
Allows fast, easy setup
High-Powered Visible Beam
For fast setup and excellent performance in high dust conditions.
Selectable Rotation Speeds
300, 600, and 900 rpm.
Intuitive, Simple Controls
Makes the GL722 easy to use and learn
Manual Vertical Capability
With the use of the Long-range Remote, vertical applications such as vineyards become simple to setup
Field Calibration
Makes it simple to check and adjust the calibration in the field either at the transmitter or via the remote
Long Battery Life
Flexible power options, battery life indicator, and a wireless operated sleep mode that saves battery during breaks
Fully Sealed, Rugged Aluminum Housing
With weather-resistant control panel, allows you to work in all weather and work conditions. Built-in non-slip carrying handle
Grade Bump
Allows you to simply raise or lower the grade remotely
Grade Reverse
Mirrors the grade setting with the push of a button
Automatic Self-Leveling
Over the entire grade range, simplifies setup and ensures repeatable accuracy
Spectra Precision Lasers
Proven performance and quality…supported by the industry’s leading service centers
Automatic Off Grade Sensor
Prevents incorrect grading … and wasted man and machine hours
Large Displays
Large displays make the numbers easy to read, even when set up on a tall tripod
Two displays, one per axis, and a radio antenna. Every keypad function also works from the RC703 remote.
Applications
Where This Laser Earns Its Keep.
Spectra Precision GL722 Laser APPLICATIONS
General construction
Building pads, slabs and parking areas: set the cross-fall and the run at the same time, from the remote.
Site preparation
Grade a pad on two axes from one setup and change grade without walking back.
Trenching
Dial the fall into the Y axis and dig to the beam.
Pipe laying
Hold the same grade along the run; temperature compensation keeps it steady.
Road construction
Cross slope on X and run on Y; Grade Match (with the 1446-8801S connector cable, sold separately for this kit) measures the slope that is already there.
Machine control
Works with laser-based machine control; run 600 or 900 rpm and change grade from the cab.
Machine control. A motor grader with a receiver mast grades to a Spectra GL722 laser on a tall tripod.Excavation. Spectra GL722 grade laser on a tripod beside a CAT 320C excavator digging to grade.
Applications from our GL722 listing and Spectra’s GL700 series datasheet.
VIDEO
See It On the Job.
Our GL722 spec walkthrough: both grade axes, the RC703 remote, Automatic Axis Alignment, Grade Match, range, accuracy and the CR600, every number from Spectra’s documents.
How It Works
Power On, Dial the Grade, Go to Work.
The GL722 has a display and a pair of grade buttons for each axis, and every function also runs from the RC703 remote. It always powers up self-leveling, and it remembers the last grades you entered.
1
Turn it on
Press power. The display shows battery charge, rotation speed and the last grade. The status LED flashes green while it self-levels; the beam starts turning when it is level.
2
Dial the grades
Each axis has its own up and down buttons: hold one until the grade you want shows on that axis. Hold longer and it moves faster. Hold both to jump to 0.000% and step in larger increments. Grades show to 0.001% up to 9.999%.
3
Pick the speed
Press the rotation button for 300, 600 or 900 rpm. Spectra: 600 rpm for hand-held receivers and most machine control.
4
Aim the axis
The axis-alignment buttons turn the grade axis electronically, like turning the laser on its tripod. Or let the RC703 do it: Automatic Axis Alignment lines the axis up on your grade rod, with the 1446-8801S cable (sold separately).
5
Let the HI alert watch it
After 15 minutes level the HI alert arms. If the tripod is bumped and the beam moves more than 1/8″, the laser shuts down the beam and rotor and the LED flashes red twice a second.
Manual mode
Press manual to bypass self-leveling: tilt the beam past the built-in grade range or work in vertical mode. The LED flashes red once a second. Press it again to go back to automatic.
Out of range?
If the laser sits outside its self-leveling range for more than 10 minutes, it shuts itself off. It also shuts off after 30 minutes if it cannot level.
Turning it off
Press and hold power for 3 seconds.
Steps from the Spectra Precision GL700 Series user guide, Rev E (Feb 2025). It is under Downloads.
The Receiver
The CR600 Works the Rod and the Machine.
Included CR600 Receiver Details: CR600 Combination Receiver
Machine or Rod Mounted Combination Receiver
Applications
Setting and Checking Elevations
Basement Excavations
Digging Septic Tanks
Checking Foundations
Digging Footings
Leveling and Setting Forms
Checking sub-base materials
Screeding concrete
Key features and benefits
Provides high, low, or on-grade information for all your grading and excavation applications up to 1,500 ft radius
In addition to handheld and rod-mounted capabilities, the CR600 system includes a C51 machine magnetic mount so it can be used as a machine-control mounted receiver in a wide range of jobsite applications
Magnesium housing is rugged but lightweight
Super-bright LED display can be easily seen by a machine operator in brightly lit conditions
270° reception for easy visibility of on-grade beam
Five on-grade sensitivities to customize need to application
Two-year warranty
Operates with red visible and infrared rotating lasers from 610 to 900 nm
CR600
Included in this package
Laser detection height
4.5 inch (114 mm)
Accuracy selections
5
Mounting
Grade rod (C50 rod clamp) or machine (C51 magnetic mount)
Display
Linear LCD plus super-bright LED grade indicators
Housing
Die-cast magnesium, rated for a 10 ft (3 m) drop onto concrete
Working radius
Up to 1,500 ft (laser dependent)
Power / battery life
3 x AA, over 100 hours (alkaline)
Weight / size
1.1 lb (0.5 kg) · 1.2 x 3.6 x 7.0 inch
Warranty
2 years, Spectra Precision
Specifications from the Spectra Precision CR600 user guide and the GL700 series datasheet.
Hover any photo to enlarge it.
The Radio Remote
The RC703 Changes Grade From Anywhere.
The reason to buy a GL722. The RC703 is a two-way, 2.4 GHz digital radio remote, encrypted to its own laser, so it never talks to the laser next door. It works up to 750 ft from the laser for everyday work and 500 ft for automatic alignment, on two AA batteries for about 100 hours. From the remote you change and bump grade, reverse the grade, change rotation speed, switch to manual and put the laser in standby, even from inside the machine cab.
⚠ No connector cable in this kit
This kit has no 1446-8801S connector cable. Without it, Automatic Axis Alignment and Grade Match do not work. The RC703 remote still changes and bumps grade from up to 750 ft. Add the 1446-8801S cable (sold separately) to use them.
1446-8801S Cable, CR600 Receiver to RC703 Remote Sold separately: $123.00
Needs the 1446-8801S cable (not in this kit). Up to 500 feet from the Transmitter. Allows simple alignment of either side of any grade axis to the desired remote point. This simple, one-person operation lets you roughly align the transmitter to within 40 degrees of the remote point. You can then go to your remote point and, with a simple button press on the wireless remote, the axis is automatically aligned. The remote provides immediate confirmation of the alignment. Automatic Axis Alignment simplifies setup and ensures repeatable accuracy. The CR600 and the RC703 go on a grade rod 60 to 500 ft from the laser (GL700 user guide).
Grade Match
Needs the 1446-8801S cable (not in this kit). Grade Match Mode allows you to match the laser to an existing slope. Simply set your receiver at the same height as the transmitter then after going to your remote point, press a button on the wireless remote to enable the transmitter to automatically match and display the grade...without returning to the laser transmitter. The laser changes grade on the chosen axis until the beam sits in the center of the receiver, then stores and shows the result.
Grade Reverse
Mirrors the grade setting with the push of a button: the same slope, the other direction, from the remote or the cab.
Grade Bump
Raise or lower the grade remotely after setup, without walking back to the laser (GL700 datasheet).
RC703
Included in this package
Radio
2.4 GHz digital, two-way, encrypted to its laser
Operating range
750 ft (225 m) general operation; 500 ft (150 m) automatic alignment
Power / battery life
2 x AA alkaline, about 100 hours
Functions
Grade change, grade bump, Grade Reverse, rotation speed, manual mode, standby; Automatic Axis Alignment and Grade Match with the 1446-8801S cable (sold separately)
Mounting
Clip for the 1446-8710 holster (grade rod), a belt or a wall screw
Warranty
2 years, Spectra Precision (with the laser)
From the Spectra Precision GL700 series user guide (Rev E, Feb 2025) and datasheet (09/23).
Specifications
Spectra Precision GL722 SPECIFICATIONS.
GL722
Spectra Precision
Leveling accuracy
3/64″ @ 100 ft · 1.2 mm @ 30 m · 8 arc seconds
Servo deadband accuracy
4.6 arc seconds
Operating diameter
3,000 ft (900 m) · 1,500 ft (460 m) radius with a receiver
Grade range
Dual: X axis -10% to +10%, Y axis -0.5% to +25%
Grade resolution
0.001%
Self-leveling range
Up to ±14° (the whole grade range)
Rotation speeds
300, 600, 900 rpm
Laser
658 nm, IEC Class 2, 3.5 mW
Power source
NiMH, 6 x D-cell; alkaline D-cells for emergency backup; external 12 V power cable optional
Battery life
About 30 hours (NiMH, at 70°F)
Recharging time
6 hours maximum
Low-battery warning
Status LED flashes yellow: under 1 hour left
Automatic shutoff
30 minutes if unable to level
Operating temperature
-4°F to 122°F (-20°C to 50°C)
Storage temperature
-40°F to 140°F (-40°C to 60°C)
Water resistance
Completely sealed and waterproof
Tripod thread
5/8-11 (3 1/2-8 and quick-disconnect optional)
Size (L x W x H)
7.75 x 10.0 x 11.75 inch (20 x 25 x 30 cm)
Weight
18.5 lb (8.4 kg)
Radio remote
RC703 two-way radio remote: 2.4 GHz digital, encrypted to its laser; 750 ft general operation, 500 ft automatic alignment; 2 x AA, about 100 hours
Remote functions
Grade change, grade bump, Grade Reverse, rotation speed, manual and standby; Automatic Axis Alignment and Grade Match with the 1446-8801S cable (sold separately)
Warranty
2 years, Spectra Precision (calibration not covered)
From the Spectra Precision GL700 series datasheet (09/23) and user guide (Rev E, Feb 2025).
Read This First
Two Things Worth Knowing.
Power: rechargeable, with an alkaline backup
The 1445-2900 NiMH battery set runs about 30 hours and recharges in 6 hours maximum on the 1445-2093 charger. When the status LED flashes yellow there is under an hour left; solid yellow means under 5 minutes. Forgot to charge? Six alkaline D-cells run it as an emergency backup, and the optional 12 V external power cable runs it off a vehicle battery. Never try to recharge alkalines.
Check calibration before the job, and after any rough handling
Spectra says to check it at the start of each job and whenever the laser has been handled roughly, and in the cold if you work below freezing. The wall check at 300 ft and the keypad adjustment are step by step in the user guide. The 2-year warranty does not cover calibration; keeping it calibrated is the owner’s job.
Compare the Kits
Which GL722 Do You Need?
Every GL722 kit has the same RC703 radio remote and CR600 receiver, the C50 clamp, C51 magnet, 1445-2900 NiMH set, charger and case. The GL722 package adds the connector cable, remote holster and 12 V power cable; the GL722-10 leaves them out; the GL722IR has the infrared beam.
RC703 REMOTE1445-2900 NIMH SET1445-2093 CHARGERC50 ROD CLAMPC51 MAG MOUNTCONNECTOR CABLEINFRARED 785 NMCARRYING CASE
$7,031.25
Want something that is not pre-built?
Pick a tripod and rod. Build your own GL722 kit.
Start the GL722 kit builder: the CR600 is picked, then choose an aluminum, fiberglass or elevator tripod and a grade rod in inches or tenths. You see the whole kit at one price.
Prices are live from our store. Every GL722 carries the 2-year Spectra laser warranty. Need a combination you do not see? Call 1-877-866-5721.
GL700 Series Comparison
How the GL722 Compares.
Same range, accuracy and Y-axis grade across the GL700 series. The GL710 is single grade; the GL720 adds the second grade axis; the GL722 adds the RC703 radio remote, Automatic Axis Alignment and Grade Match, and comes as the GL722IR with an infrared beam.
From the Spectra Precision GL700 series datasheet (09/23). Every dual grade laser we carry is on one page.
Reading the Lights
What the LEDs Are Telling You.
Status LED flashing green
Self-leveling (out of level). The beam starts rotating when it is level.
Status LED flashing red, once a second
Manual mode: the laser is not self-leveling.
Status LED flashing red, twice a second
HI alert: the setup moved. Check your elevation, then turn the laser off and on to clear it.
Status LED flashing yellow
Low battery: under one hour of running time. Solid yellow: under 5 minutes.
Status LED solid red
An internal, electronic or mechanical error. See the error codes under Troubleshooting below.
Charger: left off, right on
Charging. Left flashing, right off: charge complete. Both flashing: charging error. Both off: no connection or no batteries.
From the Spectra Precision GL700 series user guide, Rev E (Feb 2025).
QUESTIONS & ANSWERS
GL722-10 Questions We Actually Get.
Spectra Precision GL722 — straight answers. From Spectra Precision’s own documentation for the GL700 series, which we host on this site. If your question is not here, call 1-877-866-5721 and ask a person who sets these up.
Straight Answers 12
What makes the GL722-10 worth the step up?
The long-range radio remote, which the GL710 and GL720 do not carry. Grade Match Mode and Automatic Axis Alignment also need the 1446-8801S connector cable, sold separately for this kit. One person sets, changes and checks grade without returning to the laser. The -10 package pairs it with the CR600 machine-mountable receiver.
What is the grade range on a GL722-10?
Dual axis: -10 to +10% X and -0.5 to +25% Y, over a 900 metre diameter.
How far will it reach?
900 metres - 3,000 feet - in diameter, and that is the same across the whole GL700 series. The range belongs to the transmitter, not the receiver, so it does not change with which receiver you pair it with.
What rotation speeds does it run, and which should I use?
300, 600 and 900 rpm, selected from the rotation-control button. For hand-held work on a grade rod any of them is fine. If you are running a machine receiver, use 600 rpm (Spectra’s recommendation for most machine control) or faster - the faster the head spins, the more times the beam crosses the receiver every minute and the more often the operator's display updates. On a dozer or a skid steer making quick changes in elevation, a slow laser leaves the display chasing the blade.
Which receivers does it work with?
Spectra Precision HL700 and CR600 receivers, and the Trimble LR410 machine receiver. The GL700 series is part of the Trimble Grade Control System family, so it also works alongside GCS300, GCS600 and GCS900 grade control systems for automatic lift and tilt.
Does it self-level?
Yes, automatically, across the whole grade range - which is what makes setup repeatable rather than something you fiddle with. It also carries active temperature compensation, so the beam holds its plane as the day warms up rather than drifting off it.
Is it built for a jobsite?
Fully sealed rugged aluminum housing, weather-resistant control panel, a built-in non-slip carrying handle and a protective lens hood for working in bad weather. The beam is high-powered and visible, which matters in dust.
What is the warranty?
Two years. Worth knowing: calibration is specifically not covered - keeping the laser in calibration is the owner's responsibility. We can check and certify one for you; call 1-877-866-5721.
What does the radio remote actually let me do?
Change and read grade from wherever you are - including from inside the machine cab - without walking back to the transmitter. It is two-way, so the remote confirms what the laser did. There is grade bump to nudge the plane up or down, and grade reverse to mirror a grade setting with one button. On a long pull that is the difference between one man running the job and two.
What is Grade Match Mode?
It matches the laser to a slope that already exists. Set your receiver at the same height as the transmitter, go to your remote point, press a button on the remote, and the transmitter works out and displays the grade itself - without you walking back to it. Not as shipped on the GL722-10: without the 1446-8801S connector cable (sold separately) Automatic Axis Alignment and Grade Match do not work.
What is Automatic Axis Alignment?
It aligns a grade axis to a remote point up to 150 metres - 500 feet - away. Rough the transmitter in to within 40 degrees of the point, then press a button on the remote and the axis aligns itself, with confirmation on the remote. One person, no guessing, and repeatable the next time. Not as shipped on the GL722-10: without the 1446-8801S connector cable (sold separately) Automatic Axis Alignment and Grade Match do not work.
Who am I buying from?
Contractors-Tools.com, an authorized Spectra Precision dealer. We set these up every week. Tell us the work and the machines and we will spec the laser and the receiver together before you order. Call 1-877-866-5721.
Before You Buy 7
Can the GL722-10 do Grade Match or Axis Alignment?
No, not without the 1446-8801S connector cable. This kit has no 1446-8801S connector cable. Without it, Automatic Axis Alignment and Grade Match do not work. The RC703 remote still changes and bumps grade from up to 750 ft. Add the 1446-8801S cable (sold separately) to use them.
What is the Spectra GL722-10?
The Spectra Precision GL722 automatic dual grade laser packaged with the RC703 two-way radio remote and the CR600 rod and machine receiver, C50 rod clamp, C51 magnetic mount, 1445-2900 NiMH battery set, 1445-2093 charger and carrying case.
Is the GL722 a dual grade laser with a radio remote?
Yes. It sets grade on two axes, X -10% to +10% and Y -0.5% to +25%, and the RC703 two-way radio remote changes and reads grade from up to 750 ft away (500 ft for automatic alignment), per Spectra.
Can I enter a slope percentage, like 2%?
Yes, on either axis, at the laser or from the RC703 remote. The laser self-levels to the grade you enter; you do not tilt it by hand.
How accurate is the GL722?
Leveling accuracy is 3/64 inch at 100 ft (1.2 mm at 30 m, 8 arc seconds), with 4.6 arc second servo deadband accuracy and 0.001% grade resolution, per Spectra.
GL722, GL722-10 or GL722IR: which should I buy?
All three have the same RC703 remote and CR600 receiver. The GL722 package adds the 1446-8801S connector cable, 1446-8710 remote holster and 12 V power cable; the GL722-10 leaves those out; the GL722IR has a 785 nm infrared beam for work where a visible beam is not permitted. Without that cable the GL722-10 cannot run Automatic Axis Alignment or Grade Match.
How long does the battery last?
About 30 hours on the 1445-2900 NiMH battery set at 70°F, and recharging takes 6 hours maximum. Six alkaline D-cells work as an emergency backup, and the optional 1445-1770 12 V external power cable (sold separately, in Parts and Accessories below) runs it off a vehicle battery. The RC703 runs about 100 hours on two AA batteries.
Using It 5
How does Automatic Axis Alignment work?
Rough the laser in to within 40 degrees of your point, put the CR600 and the RC703 on a grade rod at the point (60 to 500 ft from the laser), and press one button on the remote: the laser turns its grade axis electronically until it lines up, and the remote confirms it. Not as shipped on the GL722-10: without the 1446-8801S connector cable (sold separately) Automatic Axis Alignment and Grade Match do not work.
How does Grade Match work?
Set the receiver at the same height as the laser, go to your remote point, and start Grade Match from the remote. The laser changes grade on the chosen axis until the beam sits in the center of the receiver, then stores and shows the grade, without you walking back to it. Not as shipped on the GL722-10: without the 1446-8801S connector cable (sold separately) Automatic Axis Alignment and Grade Match do not work.
Can I use it in vertical?
Yes, in manual mode: it bypasses self-leveling so the laser can work in vertical mode. On a tripod, vertical setup needs an after-market vertical bracket. It does not self-level in vertical.
What happens if someone bumps the tripod?
After the laser has been level for 15 minutes the HI alert is armed. If a bump moves the beam elevation more than 1/8 inch, the laser shuts down the beam and rotor and the status LED flashes red twice a second. Check your setup, then turn it off and on.
How do I check calibration?
Set up 300 ft from a wall, mark the beam, turn the laser 180 degrees and compare, per the GL700 user guide. Check at the start of each job and after rough handling. On the GL722 the adjustment can also be made from the RC703 remote.
Troubleshooting 7
The laser will not turn on.
Make sure the batteries are charged and installed correctly, and that the battery contacts are clean and in good condition.
There is no laser beam.
Make sure the laser is on and the batteries are charged, and that the laser is within its self-leveling range (up to 25%). Switching to manual mode should bring the beam back.
The receiver is not picking up the beam.
Make sure the receiver is on with good batteries and within the operating range, and check that the laser is sending a beam. Try another receiver to rule it out.
The battery life is short.
Charge with the charger plugged into a proper AC outlet for at least six hours, and use good batteries. Cold weather shortens battery life significantly.
The laser beam is not accurate.
Check and adjust calibration as described in the user guide. If it still reads wrong, return it to an authorized Spectra Precision service center.
The status LED flashes red twice a second.
That is the HI alert: the setup moved and the beam may be at the wrong elevation. Check your setup and elevation, then clear it by turning the laser off and on.
What do error codes 0004 through 8000 mean?
They are GL700 laser error codes for a hardware or software problem: 0004, 0008, 0010, 0020, 0040, 0080, 0100, 0200, 0400, 0800, 1000, 2000, 4000 and 8000. Spectra says to return the laser to an authorized Spectra Precision service center. Call us at 1-877-866-5721 and we will arrange it.
Error Codes, One by One 14
Error code 0004 on the GL722 display?
Error 0004 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0008 on the GL722 display?
Error 0008 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0010 on the GL722 display?
Error 0010 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0020 on the GL722 display?
Error 0020 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0040 on the GL722 display?
Error 0040 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0080 on the GL722 display?
Error 0080 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0100 on the GL722 display?
Error 0100 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0200 on the GL722 display?
Error 0200 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0400 on the GL722 display?
Error 0400 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 0800 on the GL722 display?
Error 0800 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 1000 on the GL722 display?
Error 1000 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 2000 on the GL722 display?
Error 2000 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 4000 on the GL722 display?
Error 4000 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
Error code 8000 on the GL722 display?
Error 8000 is one of the GL700 laser codes for a hardware or software problem. Spectra says to return the laser to an authorized Spectra Precision service center; call 1-877-866-5721 and we will arrange it.
PARTS & ACCESSORIES
Buy the Piece, Not Another Kit.
Every part of the GL722-10 package we sell on its own, plus the add-ons that fit it. If you are one piece short, buy the piece.
Questions about the GL722? Family owned and operated. We set these systems up every week — tell us the job and the laser you are running and we will spec it before you order.
